Image Syntax

To insert images in your template, you have two options:

Use an image placeholder.
Use an image text tag.

Image Placeholder

Image placeholders allow you to replace existing images in your template while preserving their size, position, and styling.

Consider the following template:

To let TemplateDocs know you want to replace the placeholder image, insert a tag in its alt text:

Right-click the placeholder image.
Select "View Alt Text...".
Insert the tag in the alt text ({{ProfilePicture}} in this example).

Provide the image details in your JSON data using the image object structure shown below:

{
  "ProfilePicture": {
    "_type": "image",
    "format": "image/png",
    "source": "https://example.com/john.png"
  },
  "FullName": "John Smith",
  "JobTitle": "Real Estate Agent",
}

The resulting document will look like this:

John SmithReal Estate Agent

Image Text Tag

If you prefer, you can still use standard template tags to insert images into the document. Simply place the tag where you want the image to appear. For example:

When you generate a document from the template, the tag will be replaced with the actual image.

Consider the following JSON data:

{
  "ProductImage": {
    "_type": "image",
    "source": "https://example.com/shoes.jpg",
    "format": "image/jpeg",
    "width": 230,
    "height": 230
  }
}

The resulting document will look like this:

Image Properties

Property	Type	Description
`_type`	string	Must be set to "image"
`source`	string	Required. URL or Base64 encoded image data
`format`	string	Required. One of: `image/png`, `image/jpeg`, `image/bmp`, or `image/gif`
`width`	number	Image width in pixels. Required when using text tags, optional when using image placeholders
`height`	number	Image height in pixels. Required when using text tags, optional when using image placeholders
`altText`	string	Optional. Alternative text for accessibility
`transparencyPercent`	number	Optional. Transparency level from 0 (opaque) to 100 (transparent)

Image files are limited to 4MB in size

Examples

URL Image Source

{
  "MyImage": {
    "_type": "image",
    "source": "https://example.com/image.png",
    "format": "image/png",
    "width": 200,
    "height": 200,
  }
}

Base64 Image Source

{
  "MyImage": {
    "_type": "image",
    "format": "image/jpeg",
    "width": 300,
    "height": 300
  }
}

Transparency and Alt Text

{
  "MyImage": {
    "_type": "image",
    "source": "https://example.com/image.jpg",
    "format": "image/jpeg",
    "width": 250,
    "height": 250,
    "transparencyPercent": 30,
    "altText": "My Image"
  }
}
